GRIP LIKE NEVER BEFORE

Smart-Lok technology

Smart-Lok is the most advanced off-road differential at your command. It's a fully lockable on-the-fly front differential with electronically-controlled automatic modes that always returns maximum traction in every condition, period

GRIP AT YOUR FINGERTIPS

Handle thrilling trails

The TRAIL ACTIV mode has been designed for aggressive riding in delivering the ultimate in cornering precision. On undulating terrain, quick corners, and loose surfaces, TRAIL ACTIV mode maximizes the 4WD system's speed, efficiency, and predictability.

When high engine torque and/or an increase in vehicle speed is detected, Smart-Lok will progressively engage (lock) the front end until the throttle is released or the vehicle’s speed is reduced. The progressive engagement allows smoother steering effort and predictable response.

Key inputs monitored: Engine torque and vehicle speed

*Smart-Lok was developed in conjunction with TEAM Industries, a market leader in the drive train industry

LEAD THE WAY

Move through deep mud

Smart-Lok is always adapting to the conditions by monitoring exactly what the vehicle’s doing over several parameters. Press the MUD button, though, and special calibrations for wet, boggy, and soft muddy terrain are engaged. MUD mode fully locks the front end when high engine torque and / or slippage are detected.

With four drive modes (2x4, locked 4x4, MUD, and TRAIL) to choose from and 8 on the hardworking Defender X mr models, you're able to overcome deeper obstacles than ever.

Key inputs monitored: engine torque and wheel speed

GET OVER IT

Drive where it rocks

A button press is all it takes to set up a Can-Am for rock crawling. With throttle, steering, and the 4WD system all tuned to maximize response over rough, rocky terrain, it's already proven with a King of the Hammers victory.

Press the ROCK button, and special calibrations kick in to help pull a Can-Am over obstacles when leading with the right front tire. When high engine torque is detected at low vehicle speed, Smart-Lok will progressively lock the front end and will stay engaged until throttle release to prevent wheel slippage and provide optimal traction. The progressive engagement also allows for easier steering when maneuvering the vehicle.

Key inputs monitored: Engine torque and throttle position

RESPONDS WITH PRECISION

LET THEM TRAIL BEHIND

When it’s all about adapting in an instant to the trail ahead, TRAIL mode uses front wheel speed sensors to compare the discrepancy and identify the slipping wheel. It will then synchronize both wheels as needed.

For a wide range of conditions, it delivers predictable cornering and traction by progressively engaging the front end and maintaining the required axle lock as the conditions and driver input change. Smart-Lok has a progressive engagement that allows for lower, smoother steering effort at higher speeds that makes TRAIL mode so surefooted.

Key inputs monitored: Wheel speed and steering angle

PACKAGES AVAILABILITY

MAVERICK X RS TURBO RR SA

RUN AT THE FRONT OF ANY PACK WITH 195 HORSEPOWER AND SMART-LOK™ DIFFERENTIAL FEATURING TRAIL ACTIV MODE.

MAIN FEATURES

  • 195 hp
  • 72 in. Width
  • Up to 24 in. (61 cm) of suspension travel
  • Smart-Shox Technology, Smart-Lok featuring 4WD TRAIL ACTIV mode
  • 30 in. Maxxis† Bighorn 2.0 tires on 14 in. cast-aluminum beadlock wheels
  • Lockable front differential with exclusive Smart-Lok™ technology. 4WD TRAIL ACTIV / 4WD TRAIL / 2WD / 4WD
  • Front suspension: Trophy truck inspired double A-arm with sway bar / Rear suspension: 4-link TTX with sway bar
  • Integrated front bumper, Quarter-doors, Full roof, 4-point harness with shoulder pads, HMWPE heavy-duty full skid plate
  • 7.6 in. digital display with keypad
  • New 850w magneto

> TECHNICAL SPECIFICATIONS
> FIND A DEALER
> REQUEST A QUOTE / DEMO RIDE

Read more

MAVERICK X DS TURBO RR

FRONT AND REAR FOX SHOCKS ARE SERIOUS HARDWARE TO HELP YOU HARNESS ALL 195 HORSES ON ANY TERRAIN, ANYWHERE—AND DO IT ALL AGAIN TOMORROW.

MAIN FEATURES

  • 195 hp
  • 64 in. Width
  • 20 in. (50.8 cm) of suspension travel
  • Smart-Lok featuring 4WD TRAIL ACTIV mode
  • 29 in. Maxxis† Bighorn 2.0 tires on 14 in. cast-aluminum beadlock wheels
  • Lockable front differential with exclusive Smart-Lok technology. 4WD TRAIL ACTIV / 4WD TRAIL
  • FOX† 2.5 PODIUM RC2† Piggyback shocks
  • Front suspension: Double A-arm with sway bar / Rear suspension: 4-link TTX with sway bar
  • Integrated front bumper, Quarter-doors, HMWPE full skid plate
  • 7.6 in. digital display with keypad, New 850w magneto, X-package graphics/seats/signature, Rear tow hook

> TECHNICAL SPECIFICATIONS
> FIND A DEALER
> REQUEST A QUOTE / DEMO RIDE

Read more

MAVERICK X MR TURBO RR

NOW WITH THE SMART-LOK™ FRONT DIFFERENTIAL AND MUD-SPECIFIC TUNING TO HAUL YOU THROUGH THE ROUGHEST CHALLENGES, IT'S THE WIDEST MAVERICK WITH 22 IN. OF SUSPENSION TRAVEL AND ARMORED 30 IN. ITP CRYPTID TIRES FOR THE ULTIMATE IN MUD PERFORMANCE

MAIN FEATURES

  • 195 hp
  • 72 in. Width
  • 22 in. (55.9 cm) of suspension travel
  • Smart-Lok featuring 4WD MUD mode
  • 30 in. ITP Cryptid† tires on 14 in. cast-aluminum beadlock wheels
  • Lockable front differential with exclusive Smart-Lok™ technology. 4WD MUD / 4WD TRAIL / 2WD / 4WD
  • FOX† 2.5 PODIUM Piggyback with QS3† shocks
  • Front suspension: Trophy truck inspired double arched A-arm with sway bar / Rear suspension: 4-link TTX with sway bar and arched lower links
  • Front bumper, Half-doors, Front and rear tow hooks, HMWPE full skid plate
  • 4,500-lb winch with synthetic rope, 7.6 in. digital display with keypad, New 850w magneto

> TECHNICAL SPECIFICATIONS
> FIND A DEALER
> REQUEST A QUOTE / DEMO RIDE

Read more

MAVERICK X RC TURBO RR

TEST YOUR METTLE AND FINALLY CONQUER THE LAST MILE: THE MAVERICK™ X3 X RC TURBO RR IS THE ULTIMATE FACTORY ROCK-CRAWLING SIDE-BY-SIDE VEHICLE FOR LEAVING RIVALS AT THE BOTTOM OF THE HEAP. FOUR-LINK TTX SUSPENSION WITH 24-IN OF TRAVEL FEATURES A TROPHY TRUCK-LIKE TRAILING ARM AND FRONT DOUBLE ARCHED A-ARM WITH SWAY BAR.

MAIN FEATURES

  • 195 hp
  • 72 in. Width
  • Up to 24 in. (61 cm) of suspension travel
  • Smart-Lok featuring 4WD ROCK mode
  • 32 in. Maxxis† Liberty 2.0 tires on 15 in. cast-aluminum beadlock wheels
  • Lockable front differential with exclusive Smart-Lok™ technology. 4WD ROCK / 4WD TRAIL / 2WD / 4WD
  • Front shocks: FOX† 2.5 PODIUM RC2† Piggyback / Rear shocks: FOX† 3.0 PODIUM RC2† Piggyback
  • Front suspension: Trophy truck inspired double arched A-arm with sway bar / Rear suspension: 4-link TTX with sway bar and arched lower links
  • Front bumper, Half-doors, Aluminum roof, Intrusion bar, 4-point harness with shoulder pads, UHMWPE rock sliders, HMWPE skidplates, Full heavy duty with differential / Under bumper / Front and rear suspension arm
  • 4,500-lb winch with synthetic rope, 7.6 in. digital display with keypad, New 850w magneto, X-package graphics/seats/signature, Rear tow hook

> TECHNICAL SPECIFICATIONS
> FIND A DEALER
> REQUEST A QUOTE / DEMO RIDE

Read more

MAVERICK X RS TURBO RR

RUN AT THE FRONT OF ANY PACK WITH 195 HORSEPOWER AND SMART-LOK™ DIFFERENTIAL FEATURING TRAIL ACTIV MODE.

MAIN FEATURES

  • 195 hp
  • 72 in. Width
  • 22 in. (55.9 cm) of suspension travel
  • Smart-Lok featuring 4WD TRAIL ACTIV mode
  • 30 in. Maxxis† Bighorn 2.0 tires on 14 in. cast-aluminum beadlock wheels
  • Lockable front differential with exclusive Smart-Lok™ technology. 4WD TRAIL ACTIV / 4WD TRAIL / 2WD / 4WD
  • Front shocks: FOX† 2.5 PODIUM RC2† Piggyback / Rear shocks: FOX† 3.0 PODIUM RC2† Piggyback
  • Front suspension: Double A-arm with sway bar and trophy truck inspired arms / Rear suspension: 4-link TTX with sway bar
  • Integrated front bumper, Quarter-doors, Full roof, 4-point harness with shoulder pads, HMWPE heavy-duty full skid plate
  • 7.6 in. digital display with keypad, New 850w magneto, X-package graphics/seats/signature, Rear tow hook

> TECHNICAL SPECIFICATIONS
> FIND A DEALER
> REQUEST A QUOTE / DEMO RIDE

Read more

MAVERICK MAX X RS TURBO RR

RUN AT THE FRONT OF ANY PACK WITH 3 OF YOUR FRIENDS, 195 HORSEPOWER & SMART-LOK™ DIFFERENTIAL FEATURING TRAIL ACTIV MODE.

MAIN FEATURES

  • 195 hp
  • 72 in. Width
  • 22 in. (55.9 cm) of suspension travel
  • Smart-Lok featuring 4WD TRAIL ACTIV mode
  • 30 in. Maxxis† Bighorn 2.0 tires on 14 in. cast-aluminum beadlock wheels
  • Lockable front differential with exclusive Smart-Lok™ technology. 4WD TRAIL ACTIV / 4WD TRAIL / 2WD / 4WD
  • Front shocks: FOX† 2.5 PODIUM RC2† Piggyback / Rear shocks: FOX† 3.0 PODIUM RC2† Piggyback
  • Front suspension: Trophy truck inspired double A-arm with sway bar / Rear suspension: 4-link TTX with sway bar
  • ntegrated front bumper, Quarter-doors, Full roof, 4-point harness with shoulder pads, HMWPE heavy-duty full skid plat
  • 7.6 in. digital display with keypad, New 850w magneto, X-package graphics/seats/signature, Rear tow hook

> TECHNICAL SPECIFICATIONS
> FIND A DEALER
> REQUEST A QUOTE / DEMO RIDE

Read more

MAVERICK MAX X RS TURBO RR SA

BUILT FOR THE VICTORY LAP. RUN AT THE FRONT OF ANY PACK WITH 3 OF YOUR FRIENDS, 195 HORSEPOWER, SMART-LOK™ DIFFERENTIAL FEATURING TRAIL ACTIV MODE AND SMART-SHOX SEMI-ACTIVE SUSPENSION.

MAIN FEATURES

  • 195 hp
  • 72 in. Width
  • 22 in. (55.9 cm) of suspension travel
  • Smart-Shox Technology, Smart-Lok featuring 4WD TRAIL ACTIV mode
  • 30 in. Maxxis† Bighorn 2.0 tires on 14 in. cast-aluminum beadlock wheels
  • Lockable front differential with exclusive Smart-Lok™ technology. 4WD TRAIL ACTIV / 4WD TRAIL / 2WD / 4WD
  • Front shoscks: FOX† 2.5 PODIUM Piggyback with bypass and Smart-Shox Technology / Rear shocks: FOX† 3.0 PODIUM Remote reservoir with bypass and Smart-Shox Technology
  • Front suspension: Trophy truck inspired double A-arm with sway bar / Rear suspension: 4-link TTX with sway bar
  • Integrated front bumper, Quarter-doors, Full roof, 4-point harness with shoulder pads, HMWPE heavy-duty full skid plate
  • 7.6 in. digital display with keypad, New 850w magneto, X-package graphics/seats/signature, Rear tow hook

> TECHNICAL SPECIFICATIONS
> FIND A DEALER
> REQUEST A QUOTE / DEMO RIDE

Read more

MAVERICK SPORT X RC 1000R

UP AND OVER IT. CONQUER THE LAST MILE WITH CAPABILITY TO SPARE: 100 HORSEPOWER, SMART-LOK ACTIVE FRONT DIFFERENTIAL AND 60-INCH WIDE STANCE BUILT TO CLIMB

MAIN FEATURES

  • Rotax® 976 cc, V-twin engine, liquid cooled 100 hp
  • 15 in. (38.1 cm) ground clearance
  • 30 in. Maxxis† Liberty 2.0 tires
  • FOX† 2.5 PODIUM Piggyback shocks with QS3†
  • Smart-Lok featuring 4WD ROCK mode
  • Integrated front steel bumper, Rear sport bumper, Mudguards, Front tow hook, 7.6 in. digital display with keypad, Full skid plate, UHMWPE rock sliders, HMWPE skid plates: Differential and front skid plate / front and rear suspension arm
  • Lockable front differential with exclusive Smart-Lok technology. 4WD ROCK / 4WD TRAIL
  • 14 in. (35.6 cm) cast-aluminum wheels
  • Front suspension: Double arched A-arm with sway bar / Rear suspension: Arched Torsional Trailing-arm (TTA) with sway bar
